portable diagnostic X-ray machine
original price: 1 000 USD
Pei Bo Lei
Contact person
Basic Information
| Brand Name | YSENMED |
|---|---|
| Model Number | YSX1101 |
| Place of Origin | China (Mainland) |
Profile & FeaturesThe product is an anti-shock, anti-scattering, single-focus, half-wave rectification and portable diagnostic X-ray machine. It can be used in medical X-ray Radiography and fluoroscopy for the oral cavity, orthopedic, heart and lung, head, contraceptive ring and the impurities in the body.Main Technical Specification Max rated capability Fluoroscopy: 75kVp,3-5mA (uncontinuous use) Common Fluoroscopy: 65kVp,3mA Max rated capability Radiography75kVp,10mA,6sIntermittent 3 minutesCurrentFluoroscopyuncontinuous,RadiographyinstantaneousPower Supply AC220V±10% ,50Hz,1kvAMoving Range of X-ray TubeVertical 220mm,Horizontal 130mmHead rotation angle of 360 degrees verticalSize of Screen 203mm x 254mm Size500mm x 310mm x 180mm Weight 25kg
Delivery terms and packaging
Packaging Detail: standard export packing Delivery Detail: 7 days
Port: GUANGZHOU
