200MA Diagnostic table and x-ray tube X-ray assemb

Number: YSX0216 Features: Single diagnostic table and single X-ray tube with rotated anode KV,mA and a interlocking protection and radiograph time-limited protection are provided Filament for stabilizing voltage, space charge compensation and anode starting-up protection device are provided Voltage of power supply and KV with digital display can be adjusted constantly and respectively It becomes convenient to install without above-ground railway and be operated easilly Electromagnetism are provided for pillar lengthways, crosswise, and sleeve moving up and down Technology Parameters DescriptionTechnology Parameters for YSX0216Power SupplyVoltageA.C.380V / 220V (±10%)Frequency50Hz ± 1HzCapacity20KVAPower Supply ResistanceA.C.380V≤1.0Ω; A.C.220V≤0.3ΩMaximum tube voltage125KVMaximum tube currency200mAFluoroscopyTube voltage40 110KVTube currency0.5 5mARadiographTube voltage40 125KVTube currencySmall Focus 25mA,50mA,100mA; Big Focus150,200mASpot film100mA (Small Focus)Time0.04 6.3s Divided into 23 grades from 0.04 6.3sHigh Voltage GeneratorCapacity20KVAX-ray TubeModelXD 51-20,40 / 125FocusSmall Focus 1×1mm2 Big Focus 2×2mm2Rotated Speed of anode2800r / minDiagnostic TableScope of rotation90° 0° -5°Mobile beam filtration deviceGrid density N=28Focus Distance fo>1000mmGrid Ratio r=8Distance from surface to film≤60mmStomach & Intestine Radiograph DeviceSpot film device specification(Stomach & Intestine Radiograph)127×178mm (5”×7”) binary picture203×254 (8”×10”) binary picture254×305 (10”×12”) binary pictureMoving lengthways (along ground railway)1500mmMoving crosswise (left & right)740mmMoving up and down700mm 1900mmWay of lockingElectromagnetism lockingBeam Limited DeviceManually single automatic multi-optional
